Anritsu MX109030PC
Virtual Network Master for AWS
Features
Operating Environment
Control Method
Functions/Performance
Virtual Network Master for AWS
The Virtual Network Master for AWS MX109030PC test application software runs on AWS Cloud servers.
Linking this application to the Network Master Pro MT1000A/MT1040A or MX109030PC measures communication line throughput, frame loss, latency time, and packet jitter every second. The MX109030PC can measure up to four data streams.
It requires a software license consisting of a basic license and time-limited licenses. Time-limited licenses are valid for 3 months or 1 year and the software is disabled when the license expires. You control measurement and view measurement results by deploying the application on an AWS Cloud server and linking to the web application via a web browser.
Linking this application to the Network Master Pro MT1000A/MT1040A or MX109030PC measures communication line throughput, frame loss, latency time, and packet jitter every second. The MX109030PC can measure up to four data streams.
It requires a software license consisting of a basic license and time-limited licenses. Time-limited licenses are valid for 3 months or 1 year and the software is disabled when the license expires. You control measurement and view measurement results by deploying the application on an AWS Cloud server and linking to the web application via a web browser.
Features
- Accurately measure communication quality, including Cloud/virtual environments
The Virtual Network Master converts the functions of physical test devices into software and operates on Cloud platforms, making it possible to set measurement points on communication paths within virtual environments.
- Accurate measurement tailored to applications
- ✓ One-way latency measurement is possible by synchronizing time with an NTP server and adding time information to all measurement frames.
- ✓ Active testing with line load and frame size tailored to applications
Operating Environment
- Platform: Amazon Web Services (AWS)
- AWS Services: Amazon Elastic Compute Cloud (Amazon EC2)
- Amazon EC2 Instance Type: C5, C6i (C5.xlarge, C6i.xlarge, and C6i.8xlarge recommended). Other non-recommended configurations are also available.
- Virtual Machine Requirements: Number of CPU cores: 4 min., RAM: 8 GB min., Storage; 16 GB min., Elastic Network Interface (ENI): 2
- Required Networks: IPv4, NTP
Control Method
- Control Method: Web GUI, Web API
- Recommended Web GUI: OS: Windows 11, Web Browser: Google Chrome
Functions/Performance
- Test Items: Frame loss count, frame loss rate, throughput, latency, jitter
